  • Description

    In the recycling and waste disposal industry, special requirements apply to the vehicles that move waste and scrap every day. Our Container Carriers are based on the robust YT and TT tractor models. As with other Terberg models, the Container Carrier is characterised by low fuel consumption, low maintenance costs and a high production rate. The robust chassis and cab design are real advantages in the operating environment of waste disposal and recycling companies. The reinforced hook lift system with 25 or 30 tonne payload and low wear and tear also proves its value during frequent roll-off and tipping operations.

    The low-noise industrial engine with SCR catalytic converter and AdBlue system contributes to a safe and comfortable workplace. The high seating position and good all-round visibility for the driver, as well as the reversing camera system with a view of the pick-up hook (option) ensure very good driving comfort.

    The Container Carrier can be used as an industrial truck for in-plant transport without a CE driving licence, and there is also the option of StVZO approval.

    The 5 advantages of terberg container carriers (compared to highway trucks):

    • Rear axle with a capacity of 38 tonnes (at 20 km/h)
    • Greatly reduced risk of damage due to the excellent view in all directions
    • Two axles are cheaper to maintain than four
    • There are no tandem tyres which suffer from friction
    • Wear of the suspension system is greatly reduced due to lower tyre friction

  • Key Points

    • Low fuel consumption
    • Low maintenance costs
    • High transfer speed
    • Reinforced hook lift system with 25 tonne payload as standard
    • Generously dimensioned and durable hydraulic components
    • Factory-fitted central lubrication system for vehicle and hook lift system (option)
    • Optionally with StVZO approval for driving on public roads
    • Long-life 6-cylinder industrial engine with SCR catalytic converter and AdBlue system
    • Ergonomics and safety equipment according to EC Machinery Directive/UVV
    • Air-suspended cab and reinforced driver’s seat ISRI 6860 Lux (option)
    • Reversing camera system with view of the pick-up hook (option)

  • SPECIFICATIONS

    YT222CC Specifications

    • Driveline: 4 x 2
    • GVW: 40t depending on operating conditions
    • Engine: Cummins B6.7-129 kW Stage V
    • Transmission: Allison 3000 (4/5F-1R)
    • Front axle capacity: 11t @20 km/h optional 16t@20km/h
    • Rear axle capacity: 30t@20km/h optional 38t@20km/h
    • Seat forward facing
    • Left and right-hand drive available
